BARNETT CROSSBOW XPX 410 210# ILLUMINATED PACKAGE 2027

The Barnett XPX™ 410 is engineered to deliver high-end ballistic performance in an accessible, reliable, and maneuverable package. Capable of launching bolts at a blistering 410 Feet Per Second (FPS), it generates massive kinetic energy, delivering flat trajectories and hard-hitting downrange impacts.

Built on a compact, well-balanced stock, the XPX 410 features a pass-through foregrip that keeps the shooter's fingers safely below the flight deck. Match-grade accuracy is provided by the TriggerTech® trigger system with Frictionless Release Technology™, offering a crisp, zero-creep 3 lb pull.

The setup also includes the Soft-Lok floating bristle arrow retainer to hold the bolt securely on the flight track, alongside an Anti-Dry Fire (ADF) safety mechanism with nock sensing to prevent accidental dry fires.

Key Features

410 FPS Velocity: Delivers high-speed performance for flat flight paths and deep downrange target penetration.
TriggerTech® 3 lb Trigger: Frictionless roller technology for a crisp release with zero creep.
Pass-Through Safety Foregrip: Keeps extended fingers safely below the flight deck rail.
Anti-Dry Fire (ADF) System: Automatic safety lockout prevents firing unless a bolt is properly loaded.
Soft-Lok™ Arrow Retainer: Floating bristle retainer holds bolts securely while dampening noise and vibration.
CNC Machined Aluminum Track: Ensures smooth bolt flight and long-term durability.

Technical Specifications

Specification	Details
Manufacturer	Barnett Crossbows
Model	XPX™ 410
Speed (FPS)	410 Feet Per Second (~450 km/h)
Kinetic Energy	~135 ft-lbs
Draw Weight	200 lbs
Power Stroke	13.8 Inches (~35 cm)
Axle-to-Axle Width	~13'' (Cocked) / ~16.5'' (Uncocked)
Overall Length	33 Inches (~83.8 cm)
Bare Bow Weight	~6.9 lbs (3.1 kg)
Optics Included	4x32mm Multi-Reticle Scope
Trigger Mechanism	TriggerTech Frictionless Release Technology (3 lbs)
Arrow Compatibility	Standard 20'' arrows with .300'' diameter (e.g., Barnett Headhunter™ 20'')

Package Contents (Ready-to-Shoot Package)

1× Barnett XPX™ 410 Compound Crossbow
1× 4x32mm Multi-Reticle Scope
2× 20'' Barnett Headhunter™ Carbon Arrows
1× Quick-Detach Side-Mount Quiver
1× Sled-Style Rope Cocking Device
1× Rail & String Lubricating Wax

Compatibility & Recommended Accessories

Compatible Arrows: Uses standard-diameter (.300'' ID) 20'' carbon arrows, such as the Barnett Headhunter™ 20'' series. Not compatible with .204'' micro-diameter (HyperFlite™) arrows.
Cranking Device: Compatible with Barnett universal crank cocking devices (Universal Crank Cocking Device).
